Optimal for longer unattended dry storage operations.

After properly connecting the condensate pump to the unit and starting the drying process, the sump of the pump gradually fills with water. When a certain water level is reached, the pump turns on automatically and drains the water through the connected hose. The pump then switches off again until the level in the collection tray rises again.

The automatic shut-off of the dehumidifier is stopped as soon as the extracted liquid needs to be pumped out with the condensate pump.

Technical data:

• Voltage: 220 V (50/60 Hz);
• Power: 58/55 watts;
• Maximum suction height: 3.90 m;
• A non-return valve;
• Water hose inlet: 25 mm (maximum outer diameter);
• Water hose outlet: 5 mm (inner diameter);
• Dimensions: 280 mm x 125 mm x 140 mm;
• Weight: about 1.9 kg;
• Capacity: 90 l/h at a delivery height of 3 m.

Condensate pump for the following Trotec commercial dehumidifiers ECO and TTK-S series:

• TTK 75 ECO;
• TTK 166 ECO;
• TTK 170 ECO;
• TTK 171 ECO;
• TTK 140 S 2013 model;
• TTK 170 S 2013 model;
• TTK 350 S 2013 model;
• TTK 650 S 2013 model.
